Short-travel XC with Canyon's longer modern reach. It sprints like an XC bike and is less of a downcountry slacker than some 120 mm peers.
XC racers and fit riders who want a lightweight 29er, not a trail bike in disguise.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 588 mm | 420 mm | 1.40:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.5° | 75.5° | 432 mm | 1140 mm | 44 mm | 29" |
| M | 597 mm | 445 mm | 1.34:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.5° | 75.5° | 432 mm | 1165 mm | 44 mm | 29" |
| L | 611 mm | 470 mm | 1.30:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.5° | 75.5° | 432 mm | 1194 mm | 44 mm | 29" |
| XL | 625 mm | 495 mm | 1.26:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.5° | 75.5° | 432 mm | 1223 mm |
This year's studio shot is Lux WC CFR SRAM.
Same published geometry as 2024.
No verified spec sheet for 2025 or 2024.
No launch MSRP in the catalog yet.
| 44 mm |
| 29" |
