Quintana Roo V-PR 2026 geometry

No OEM studio shot for this year yet.

Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: tt.

Size	Stack	Reach	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop
L	552 mm	420 mm	73.0°	77.5°	400 mm	1006 mm	64 mm
M	532 mm	412 mm	73.0°	77.5°	400 mm	994 mm	64 mm
S	512 mm	404 mm	72.5°	78.0°	400 mm	982 mm	66 mm
XL	572 mm	428 mm	73.5°	77.0°	400 mm	1020 mm	62 mm
XS	492 mm	396 mm	72.0°	78.0°	400 mm	972 mm	66 mm

What it's like to ride

A time-trial / triathlon bike. Stack and reach only make sense in aero bars; do not twin this with a road-race fit. Size M sits around 532 mm stack and 412 mm reach, 73° head angle, 400 mm chainstays.

Who it's for

Time trialists and triathletes. Compare with other TT bikes, not road race bikes.

Manufacturer trims

V-PR Shimano 105 Di2

MSRP not listed

Component	Brand	Model	Size
Shifters	Shimano	ST-R7120 105 HRD	2×12
Front derailleur	Shimano	FD-R7100 105	braze-on
Rear derailleur	Shimano	RD-R7100 105	12-speed
Crankset	Shimano	FC-R7100 105	50/34 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R7100 105	11-34, 12-speed
Chain	Shimano	CN-M7100 SLX	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R7170 105

Similar bikes

Size guidance

Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.

Component	Brand	Model	Size
Shifters	SRAM	Rival AXS E1 HRD	2×12
Front derailleur	SRAM	Rival AXS E1	braze-on
Rear derailleur	SRAM	Rival AXS E1	12-speed
Crankset	SRAM	Rival E1	48/35 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	SRAM	XG-1250 E1	10-36, 12-speed
Chain	SRAM	Rival E1 Flattop	12-speed
Power meter	—	None	—
Brakes	SRAM	Rival AXS E1 HRD	hydraulic disc
Rotors	SRAM	Paceline	160mm centerlock
Bottom bracket	SRAM	DUB T47	internal bearing
Wheels	Alloy	road wheelset	700c
Tires	700x28mm	road	—

Component	Brand	Model	Size
Shifters	SRAM	Force AXS E1 HRD	2×12
Front derailleur	SRAM	Force AXS E1	braze-on
Rear derailleur	SRAM	Force AXS E1	12-speed
Crankset	SRAM	Force E1	48/35 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	SRAM	XG-1270 E1	10-33, 12-speed
Chain	SRAM	Force E1 Flattop	12-speed
Power meter	—	None	—
Brakes	SRAM	Force AXS E1 HRD	hydraulic disc
Rotors	SRAM	Paceline X	160mm centerlock
Bottom bracket	SRAM	DUB T47	internal bearing
Wheels	40–50	mm carbon wheelset	700c
Tires	700x28mm	road	—

Component	Brand	Model	Size
Shifters	SRAM	RED AXS E1 HRD	2×12
Front derailleur	SRAM	RED AXS E1	braze-on
Rear derailleur	SRAM	RED AXS E1	36T max
Crankset	SRAM	RED AXS E1 with power meter	48/35 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	SRAM	XG-1290 E1	10-33, 12-speed
Chain	SRAM	RED E1 Flattop	12-speed
Power meter	SRAM	RED AXS E1	spindle
Brakes	SRAM	RED AXS E1 HRD	hydraulic disc
Rotors	SRAM	Paceline X	160mm centerlock
Bottom bracket	SRAM	DUB T47	internal bearing
Wheels	50–51	mm carbon aero wheelset	700c
Tires	700x28mm	road	—

Size	Stem	Bar	Crank
L	110 mm	440 mm	175 mm
M	100 mm	420 mm	173 mm
S	90 mm	400 mm	170 mm
XL	110 mm	440 mm	175 mm
XS	80 mm	380 mm	165 mm

Quintana Roo V-PR 2026 geometry

What it's like to ride

Who it's for

Manufacturer trims

V-PR Shimano 105 Di2

Similar bikes

Size guidance

Quintana Roo V-PR 2026 geometry

What it's like to ride

Who it's for

Manufacturer trims

V-PR Shimano 105 Di2

Similar bikes

Size guidance

V-PR SRAM Rival AXS

V-PR Shimano Ultegra Di2

V-PR SRAM Force AXS

V-PR Shimano Dura-Ace Di2

V-PR SRAM RED AXS

Cockpit by size

Reviews

Component	Brand	Model	Size
Shifters	Shimano	ST-R8170 Ultegra Di2 HRD	2×12
Front derailleur	Shimano	FD-R8150 Ultegra Di2	braze-on
Rear derailleur	Shimano	RD-R8150 Ultegra Di2	12-speed
Crankset	Shimano	FC-R8100 Ultegra	52/36 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R8100 Ultegra	11-30, 12-speed
Chain	Shimano	CN-M8100 Ultegra	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R8170 Ultegra	hydraulic disc
Rotors	Shimano	SM-RT800	160mm / 140mm centerlock
Wheels	40–50	mm carbon wheelset	700c
Tires	700x28mm	road	—

Component	Brand	Model	Size
Shifters	Shimano	ST-R9270 Dura-Ace Di2 HRD	2×12
Front derailleur	Shimano	FD-R9250 Dura-Ace Di2	braze-on
Rear derailleur	Shimano	RD-R9250 Dura-Ace Di2	12-speed
Crankset	Shimano	FC-R9200 Dura-Ace HollowTech II	52/36 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R9200 Dura-Ace	11-30, 12-speed
Chain	Shimano	CN-M9100 Dura-Ace	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R9270 Dura-Ace	hydraulic disc
Rotors	Shimano	RT-MT900	160mm front / 140mm rear
Wheels	50–51	mm carbon aero wheelset	700c
Tires	700x28mm	road	—
