Loading geometry
XC race Orbea. Short travel, World Cup intent, unhappy as a trail bike.
XC racers. Occam for trail.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 588 mm | 425 mm | 1.38:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.0° | 75.5° | 432 mm | 1138 mm | 42 mm | 29" |
| M | 597 mm | 450 mm | 1.33:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.0° | 75.5° | 432 mm | 1164 mm | 42 mm | 29" |
| L | 606 mm | 475 mm | 1.28:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.0° | 75.5° | 432 mm | 1191 mm | 42 mm | 29" |
| XL | 620 mm | 500 mm | 1.24:1 | 50 mm | 800 mm | 175 mm | 145 mm | 67.0° | 75.5° | 432 mm | 1220 mm |
This year's studio shot is year-true studio.
This is the earliest Oiz year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
Orbea Oiz M20 29 (2017) review - MBRMBR · 2017
First Ride Review: 2019 Orbea OizSingletrack · 2019
Orbea Oiz M30 Long Term ReviewYouTube · 2019
Orbea Oiz - First Ride ReviewYouTube · 2019
Orbea Oiz 2021 Review | A race bike with an ace up its ...Flow Mountain Bike · 2020| 42 mm |
| 29" |
