Trek Top Fuel 2022 Geometry, Reviews, and Specs

Fit and steering

Aggressive fitSlow steeringFast steeringRelaxed fit

Weight—

Climbing10.0

Aero0.0

Comfort0.0

Shorter-travel and quicker than Fuel EX. It pedals toward XC and still descends like a modern downcountry bike in recent years.

Riders who want a fast 29er without Fuel EX travel. XC-curious trail riders.

Size	Stack	Reach	Stack/reach	Stem	Bar	Crank	Dropper	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop	Wheel size
S	570 mm	417 mm	1.37:1	50 mm	800 mm	175 mm	170 mm	65.5°	76.0°	435 mm	1151 mm	16 mm	29"
M	603 mm	447 mm	1.35:1	50 mm	800 mm	175 mm	170 mm	65.5°	76.9°	435 mm	1188 mm	32 mm	29"
ML	607 mm	462 mm	1.31:1	50 mm	800 mm	175 mm	170 mm	65.5°	76.2°	440 mm	1210 mm	32 mm	29"
L	612 mm	477 mm	1.28:1	50 mm	800 mm	175 mm	170 mm	65.5°	75.9°	440 mm	1227 mm

This year's studio shot is Top Fuel C Frameset.

This is the earliest Top Fuel year in the catalog. No prior year to compare.

The Trek Top Fuel moves further away from its XC racing roots with an updated chassis and a more progressive approach to the geometry. This thing rips!
