Revel Rail 2026 Geometry, Reviews, and Specs

No OEM studio shot for this model yet.

Fit and steering

Aggressive fitSlow steeringFast steeringRelaxed fit

Weight—

Climbing10.0

Aero0.0

Comfort0.0

Size	Stack	Reach	Stack/reach	Stem	Bar	Crank	Dropper	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop	Wheel size
S	618 mm	438 mm	1.41:1	50 mm	800 mm	175 mm	190 mm	64.0°	77.2°	436 mm	1216 mm	26 mm	29"
M	628 mm	463 mm	1.36:1	50 mm	800 mm	175 mm	190 mm	64.0°	77.2°	436 mm	1243 mm	26 mm	29"
L	638 mm	488 mm	1.31:1	50 mm	800 mm	175 mm	190 mm	64.0°	77.2°	436 mm	1270 mm	26 mm	29"
XL	652 mm	513 mm	1.27:1	50 mm	800 mm	175 mm	190 mm	64.0°	77.2°	436 mm	1300 mm

No colorway catalog for 2026 yet.

Same published geometry as 2025.

Published geometry matches the 2025 Revel Rail. Same sizes, same stack and reach.

No verified spec sheet for 2026 or 2025.

The Revel Rail is a long travel enduro mountain bike with 27.5” wheels. With 165mm of rear travel and the Canfield Balance Formula ...

No launch MSRP in the catalog yet.
