Loading geometry
Trail Cannondale. Modern reach, trail travel, and a personality between Scalpel XC and Jekyll enduro.
Trail riders who want one Cannondale.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 608 mm | 430 mm | 1.41:1 | 50 mm | 800 mm | 175 mm | 170 mm | 65.0° | 77.0° | 440 mm | 1195 mm | 35 mm | 29" |
| M | 618 mm | 455 mm | 1.36:1 | 50 mm | 800 mm | 175 mm | 170 mm | 65.0° | 77.0° | 440 mm | 1222 mm | 35 mm | 29" |
| L | 628 mm | 480 mm | 1.31:1 | 50 mm | 800 mm | 175 mm | 170 mm | 65.0° | 77.0° | 440 mm | 1249 mm | 35 mm | 29" |
| XL | 642 mm | 505 mm | 1.27:1 | 50 mm | 800 mm | 175 mm | 170 mm | 65.0° | 77.0° | 440 mm | 1278 mm |
No colorway catalog for 2027 yet.
Same published geometry as 2026.
Same verified builds as 2026.
Launch MSRP held versus 2026.
$2,300 · 2027 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | Shimano Deore 12-speed | 1×12 |
| Rear derailleur | Shimano | Shimano Deore 12-speed | — |
| Crankset | Shimano | Shimano Deore 12-speed |
|
| Cassette | Shimano | 12-speed | — |
| Chain | Shimano | 12-speed | — |
| Power meter | — | None | — |
| Brakes | Shimano | hydraulic disc | — |
| Rotors | Shimano | 180mm | — |
| Wheels | Alloy | 29" wheelset | 700c |
| Tires | 29×2.4" | trail | — |
| Fork | 130–150 | mm trail fork | — |
| Shock | Matching | trail shock | — |
| Dropper | 150–170 |
| 35 mm |
| 29" |
| mm dropper |
| — |
$3,325 · 2027 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | Shimano Deore 12-speed | 1×12 |
| Rear derailleur | Shimano | Shimano Deore 12-speed | — |
| Crankset | Shimano | Shimano Deore 12-speed |
|
| Cassette | Shimano | 12-speed | — |
| Chain | Shimano | 12-speed | — |
| Power meter | — | None | — |
| Brakes | Shimano | hydraulic disc | — |
| Rotors | Shimano | 180mm | — |
| Wheels | Alloy | 29" wheelset | 700c |
| Tires | 29×2.4" | trail | — |
| Fork | 130–150 | mm trail fork | — |
| Shock | Matching | trail shock | — |
| Dropper | 150–170 | mm dropper | — |
