XC hardtail with Trek's IsoSpeed carbon idea on many years. Light, stiff, and race-steep compared with Roscoe or Marlin.
XC racers and fit riders who want a hardtail, not a trail 29er.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 607 mm | 395 mm | 1.54:1 | 50 mm | 800 mm | 175 mm | 145 mm | 68.8° | 74.0° | 430 mm | 1095 mm | 58 mm | 29" |
| M | 611 mm | 420 mm | 1.45:1 | 50 mm | 800 mm | 175 mm | 145 mm | 68.8° | 74.0° | 430 mm | 1120 mm | 58 mm | 29" |
| ML | 615 mm | 435 mm | 1.41:1 | 50 mm | 800 mm | 175 mm | 145 mm | 68.8° | 74.0° | 430 mm | 1135 mm | 58 mm | 29" |
| L | 624 mm | 450 mm | 1.39:1 | 50 mm | 800 mm | 175 mm | 145 mm | 68.8° | 74.0° | 430 mm | 1154 mm |
This year's studio shot is Procaliber 6.
Same published geometry as 2023.
No verified spec sheet for 2024 or 2023.
No launch MSRP in the catalog yet.
| 58 mm |
| 29" |
| XL | 643 mm | 475 mm | 1.35:1 | 50 mm | 800 mm | 175 mm | 145 mm | 68.8° | 74.0° | 430 mm | 1188 mm | 58 mm | 29" |
