Aggressive fitSlow steeringFast steeringRelaxed fit
Weight—
Climbing10.0
Aero0.0
Comfort0.0
Bold Unplugged 2018 Sizing Guide
Bold Unplugged 2018 Geometry Chart
Size
Stack
Reach
Stack/reach
Stem
Bar
Crank
Dropper
Head tube angle
Seat tube angle
Chainstay
Wheelbase
BB drop
Wheel size
S
606 mm
428 mm
1.42:1
50 mm
800 mm
175 mm
170 mm
65.5°
76.5°
432 mm
1174 mm
36 mm
29"
M
616 mm
453 mm
1.36:1
50 mm
800 mm
175 mm
170 mm
65.5°
76.5°
432 mm
1201 mm
36 mm
29"
L
626 mm
478 mm
1.31:1
50 mm
800 mm
175 mm
170 mm
65.5°
76.5°
432 mm
1228 mm
36 mm
29"
XL
640 mm
503 mm
1.27:1
50 mm
800 mm
175 mm
170 mm
65.5°
76.5°
432 mm
1258 mm
What's new for the 2018 year
2018 colorways
No colorway catalog for 2018 yet.
What changed in the bike frame
This is the earliest Unplugged year in the catalog. No prior year to compare.
The Bold Unplugged not only looks super fast, it is super fast. The potent geometry inspires confidence even in the most demanding terrain, enabling you to ...
What changed in equipment
No verified spec sheet for 2018 yet.
The Bold Unplugged offers 164mm of rear travel and can run forks from 160mm to 180mm. In addition to the ability to run a range of forks, the bike is highly ...
