Loading geometry
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 604 mm | 424 mm | 1.42:1 | 50 mm | 800 mm | 175 mm | 170 mm | 66.5° | 75.5° | 428 mm | 1164 mm | 42 mm | 29" |
| M | 614 mm | 449 mm | 1.37:1 | 50 mm | 800 mm | 175 mm | 170 mm | 66.5° | 75.5° | 428 mm | 1191 mm | 42 mm | 29" |
| L | 624 mm | 474 mm | 1.32:1 | 50 mm | 800 mm | 175 mm | 170 mm | 66.5° | 75.5° | 428 mm | 1218 mm | 42 mm | 29" |
| XL | 638 mm | 499 mm | 1.28:1 | 50 mm | 800 mm | 175 mm | 170 mm | 66.5° | 75.5° | 428 mm | 1248 mm |
No colorway catalog for 2014 yet.
This is the earliest Maynard year in the catalog. No prior year to compare.
No verified spec sheet for 2014 yet.
No launch MSRP in the catalog yet.
We couldn't find any reviews for this model year.
| 42 mm |
| 29" |
