Loading geometry
Downhill race bike. Slack, long-travel, and unhappy if you try to pedal it like a Slash on a fire road.
DH and bike-park specialists. Not an all-mountain trail bike.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Dropper | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 620 mm | 430 mm | 1.44:1 | 50 mm | 800 mm | 175 mm | 190 mm | 63.0° | 77.5° | 445 mm | 1235 mm | 10 mm | 29" |
| M | 629 mm | 455 mm | 1.38:1 | 50 mm | 800 mm | 175 mm | 190 mm | 63.0° | 77.5° | 445 mm | 1262 mm | 10 mm | 29" |
| L | 638 mm | 480 mm | 1.33:1 | 50 mm | 800 mm | 175 mm | 190 mm | 63.0° | 77.5° | 445 mm | 1289 mm | 10 mm | 29" |
| XL | 647 mm | 505 mm | 1.28:1 | 50 mm | 800 mm | 175 mm | 190 mm | 63.0° | 77.5° | 445 mm | 1316 mm |
No colorway catalog for 2024 yet.
Same published geometry as 2023.
No verified spec sheet for 2024 or 2023.
No launch MSRP in the catalog yet.
| 10 mm |
| 29" |
