Loading geometry
BMC endurance road: taller stack, more compliance, all-day. Still Swiss-precise steering compared with some endurance bikes.
Sportive riders who found Teammachine too low.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 525 mm | 362 mm | 1.45:1 | 70 mm | 360 mm | 165 mm | 71.0° | 73.5° | 415 mm | 985 mm | 75 mm | 700c |
| 51 | 548 mm | 370 mm | 1.48:1 | 90 mm | 400 mm | 170 mm | 71.5° | 73.5° | 415 mm | 994 mm | 75 mm | 700c |
| 54 | 570 mm | 377 mm | 1.51:1 | 100 mm | 420 mm | 172.5 mm | 72.0° | 73.5° | 415 mm | 1004 mm | 73 mm | 700c |
| 56 | 590 mm | 383 mm | 1.54:1 | 100 mm | 420 mm | 172.5 mm | 72.0° | 73.5° | 415 mm | 1014 mm | 73 mm | 700c |
| 58 | 610 mm |
No colorway catalog for 2025 yet.
Same published geometry as 2024.
No verified spec sheet for 2025 or 2024.
No launch MSRP in the catalog yet.
| 389 mm |
| 1.57:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 72.5° |
| 73.5° |
| 415 mm |
| 1026 mm |
| 71 mm |
| 700c |
| 61 | 630 mm | 395 mm | 1.59:1 | 110 mm | 440 mm | 175 mm | 72.5° | 73.5° | 415 mm | 1038 mm | 71 mm | 700c |
