Loading geometry
Taller stack, longer stays, and calmer steering than the Ultimate. It still pedals like a Canyon road bike, but it takes the edge off chipseal and all-day hours.
Sportives, gran fondos, and riders coming off a race bike who want more stack without going full gravel.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2XS | 530 mm | 360 mm | 1.47:1 | 70 mm | 360 mm | 165 mm | 70.0° | 73.5° | 415 mm | 990 mm | 75 mm | 700c |
| XS | 548 mm | 368 mm | 1.49:1 | 80 mm | 380 mm | 165 mm | 71.0° | 73.5° | 415 mm | 998 mm | 75 mm | 700c |
| S | 570 mm | 374 mm | 1.52:1 | 90 mm | 400 mm | 170 mm | 72.0° | 73.5° | 415 mm | 1005 mm | 75 mm | 700c |
| M | 594 mm | 380 mm | 1.56:1 | 100 mm | 420 mm | 172.5 mm | 72.5° | 73.5° | 415 mm | 1012 mm | 75 mm | 700c |
| L | 618 mm |
These are the 2022 colors.
This is the earliest Endurace CF year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
2022 Canyon Endurace CF 7 All-Road in reviewGRAN FONDO Cycling Magazine · 2022
Canyon present the 2022 Endurace CF and ALGRAN FONDO Cycling Magazine · 2022
Canyon launches new affordable Endurace CF and AL ...Velo · 2022
Canyon Endurace CF 7 eTap reviewBikeRadar · 2022
Canyon Endurace CF 8 review - top value carbon comfortCycling Weekly · 2022| 386 mm |
| 1.60:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 72.5° |
| 73.5° |
| 415 mm |
| 1024 mm |
| 73 mm |
| 700c |
| XL | 642 mm | 392 mm | 1.64:1 | 110 mm | 440 mm | 175 mm | 73.0° | 73.5° | 415 mm | 1035 mm | 73 mm | 700c |
