Loading geometry
Taller stack, longer stays, and calmer steering than the Ultimate. It still pedals like a Canyon road bike, but it takes the edge off chipseal and all-day hours.
Sportives, gran fondos, and riders coming off a race bike who want more stack without going full gravel.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2XS | 530 mm | 360 mm | 1.47:1 | 70 mm | 360 mm | 165 mm | 70.0° | 73.5° | 415 mm | 990 mm | 75 mm | 700c |
| XS | 548 mm | 368 mm | 1.49:1 | 80 mm | 380 mm | 165 mm | 71.0° | 73.5° | 415 mm | 998 mm | 75 mm | 700c |
| S | 570 mm | 374 mm | 1.52:1 | 90 mm | 400 mm | 170 mm | 72.0° | 73.5° | 415 mm | 1005 mm | 75 mm | 700c |
| M | 594 mm | 380 mm | 1.56:1 | 100 mm | 420 mm | 172.5 mm | 72.5° | 73.5° | 415 mm | 1012 mm | 75 mm | 700c |
| L | 618 mm |
Same OEM palette as 2023.
Same published geometry as 2023.
No verified spec sheet for 2024 or 2023.
No launch MSRP in the catalog yet.
| 386 mm |
| 1.60:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 72.5° |
| 73.5° |
| 415 mm |
| 1024 mm |
| 73 mm |
| 700c |
| XL | 642 mm | 392 mm | 1.64:1 | 110 mm | 440 mm | 175 mm | 73.0° | 73.5° | 415 mm | 1035 mm | 73 mm | 700c |
