Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 2XS). Category: road-endurance.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 2XS | 530 mm | 360 mm | 70.0° | 73.5° | 415 mm | 990 mm | 75 mm |
| L | 618 mm | 386 mm | 72.5° | 73.5° | 415 mm | 1024 mm | 73 mm |
| M | 594 mm | 380 mm | 72.5° | 73.5° | 415 mm | 1012 mm | 75 mm |
| S | 570 mm | 374 mm | 72.0° | 73.5° | 415 mm | 1005 mm | 75 mm |
| XL | 642 mm | 392 mm | 73.0° | 73.5° | 415 mm | 1035 mm | 73 mm |
| XS | 548 mm | 368 mm | 71.0° | 73.5° | 415 mm | 998 mm | 75 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
