Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: mtb-trail.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 629 mm | 480 mm | 65.5° | 76.5° | 435 mm | 1241 mm | 38 mm |
| M | 620 mm | 455 mm | 65.5° | 76.5° | 435 mm | 1214 mm | 38 mm |
| S | 611 mm | 430 mm | 65.5° | 76.5° | 435 mm | 1187 mm | 38 mm |
| XL | 643 mm | 505 mm | 65.5° | 76.5° | 435 mm | 1270 mm | 38 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
