Colnago's lugged-carbon flagship. More of a beautiful all-rounder than a pure V-series race whip, with a size run in Colnago's s-suffix chart.
Riders who want a Colnago that isn't a WorldTour V4Rs. More comfort and presence than the V bikes.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 42s | 505 mm | 370 mm | 1.36:1 | 70 mm | 360 mm | 165 mm | 70.6° | 75.0° | 408 mm | 970 mm | 74 mm | 700c |
| 45s | 520 mm | 376 mm | 1.38:1 | 70 mm | 360 mm | 165 mm | 71.0° | 74.5° | 408 mm | 976 mm | 74 mm | 700c |
| 48s | 535 mm | 382 mm | 1.40:1 | 80 mm | 380 mm | 165 mm | 71.5° | 74.0° | 410 mm | 984 mm | 72 mm | 700c |
| 50s | 550 mm | 386 mm | 1.42:1 | 80 mm | 380 mm | 165 mm | 72.0° | 73.5° | 410 mm | 990 mm | 72 mm | 700c |
| 52s | 568 mm |
This year's studio shot is C68 launch white background.
This is the earliest C68 year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
Colnago C68 with C60 Wheels vs Princeton Wake 6560YouTube · 2019
Colnago C68 Road | Rediscover the sheer joy of ridingYouTube · 2019
New Colnago C68 Gravel bike: ride impressions and detailsYouTube · 2019| 390 mm |
| 1.46:1 |
| 90 mm |
| 400 mm |
| 170 mm |
| 72.5° |
| 73.0° |
| 412 mm |
| 998 mm |
| 70 mm |
| 700c |
| 54s | 586 mm | 394 mm | 1.49:1 | 100 mm | 420 mm | 172.5 mm | 72.8° | 73.0° | 412 mm | 1008 mm | 70 mm | 700c |
| 56s | 604 mm | 398 mm | 1.52:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 72.5° | 414 mm | 1018 mm | 68 mm | 700c |
| 58s | 622 mm | 402 mm | 1.55:1 | 110 mm | 440 mm | 175 mm | 73.0° | 72.5° | 414 mm | 1028 mm | 68 mm | 700c |
