Bikes / Trek / Boone

Trek Boone 2022 Geometry, Reviews, and Specs

Fit and steering

Aggressive fitSlow steeringFast steeringRelaxed fit

Weight—

Climbing4.0

Aero5.0

Comfort6.0

A UCI cyclocross race bike with IsoSpeed on some generations. Tight, muddy, and built to be shouldered — not a Checkpoint with CX tires.

CX racers. If you want gravel capability, look at Checkpoint or Checkmate instead.

Size	Stack	Reach	Stack/reach	Stem	Bar	Crank	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop	Wheel size
49	530 mm	375 mm	1.41:1	80 mm	380 mm	165 mm	71.0°	74.5°	425 mm	1008 mm	68 mm	700c
52	548 mm	382 mm	1.43:1	90 mm	400 mm	170 mm	71.5°	74.0°	425 mm	1018 mm	68 mm	700c
54	565 mm	388 mm	1.46:1	100 mm	420 mm	172.5 mm	72.0°	73.7°	425 mm	1028 mm	66 mm	700c
56	583 mm	394 mm	1.48:1	100 mm	420 mm	172.5 mm	72.0°	73.5°	425 mm	1038 mm	66 mm	700c
58	602 mm

This year's studio shot is Boone 6 Disc.

This is the earliest Boone year in the catalog. No prior year to compare.

The Trek Boone 5 Can Tackle the Toughest 'Cross Races ... With a carbon frame built to absorb shocks, the Boone can crush cyclocross races, smooth the roughest ...
