Bikes / Cotic / Cascade
Cotic Cascade 2022 Geometry, Reviews, and Specs
Fit and steering
Aggressive fitSlow steeringFast steeringRelaxed fit Cotic Cascade 2022 Sizing Guide
Cotic Cascade 2022 Geometry Chart
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|
| S | 576 mm | 380 mm | 1.52:1 | 90 mm | 400 mm | 170 mm | 69.5° | 73.5° | 445 mm | 1058 mm | 68 mm | 700c |
| M | 594 mm | 390 mm | 1.52:1 | 100 mm | 420 mm | 172.5 mm | 70.0° | 73.0° | 445 mm | 1070 mm | 68 mm | 700c |
| L | 612 mm | 400 mm | 1.53:1 | 110 mm | 440 mm | 175 mm | 70.0° | 73.0° | 445 mm | 1082 mm | 66 mm | 700c |
| XL | 630 mm | 410 mm | 1.54:1 | 110 mm | 440 mm | 175 mm | 70.5° | 72.5° | 445 mm | 1096 mm | 66 mm | 700c |
2022 colorways
No colorway catalog for 2022 yet.
What changed in the bike frame
Same published geometry as 2021.
- Published geometry matches the 2021 Cotic Cascade. Same sizes, same stack and reach.
What changed in equipment
No verified spec sheet for 2022 or 2021.
What changed in price
No launch MSRP in the catalog yet.
Compare 2022 and 2021 Cotic Cascade side by side
