Loading geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: road-endurance.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 585 mm | 384 mm | 72.5° | 73.0° | 415 mm | 1014 mm | 73 mm |
| M | 567 mm | 378 mm | 72.0° | 73.5° | 415 mm | 1004 mm | 73 mm |
| S | 549 mm | 372 mm | 71.5° | 73.5° | 415 mm | 996 mm | 75 mm |
| XL | 603 mm | 390 mm | 72.8° | 73.0° | 415 mm | 1026 mm | 71 mm |
| XS | 531 mm | 366 mm | 71.0° | 74.0° | 415 mm | 988 mm | 75 mm |
| XXL | 621 mm | 396 mm | 73.0° | 72.5° | 415 mm | 1038 mm | 71 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
