Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: cyclocross.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 592 mm | 398 mm | 72.5° | 73.0° | 425 mm | 1048 mm | 64 mm |
| M | 574 mm | 392 mm | 72.0° | 73.5° | 425 mm | 1036 mm | 66 mm |
| S | 556 mm | 386 mm | 72.0° | 73.5° | 425 mm | 1026 mm | 66 mm |
| XL | 610 mm | 404 mm | 72.5° | 73.0° | 425 mm | 1060 mm | 64 mm |
| XS | 538 mm | 380 mm | 71.5° | 74.0° | 425 mm | 1016 mm | 68 mm |
| XXS | 520 mm | 374 mm | 71.0° | 74.5° | 425 mm | 1008 mm | 68 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
