The light gravel/CX race bike: lower and snappier than Diverge, with less adventure hardware. It feels like a Tarmac that grew tire clearance.
CX and gravel racers who size like a road-race bike. If you want Future Shock and mounts, Diverge is the sibling.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Top tube | Seat tube | Head tube | Head tube angle | Seat tube angle | Chainstay | Wheelbase | Front center | BB drop | BB height | Fork rake | Trail | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 530 mm | 375 mm | 1.41:1 | 80 mm | 380 mm | 165 mm | 512 mm | 445 mm | 95 mm | 70.5° | 75.5° | 425 mm | 1008 mm | 594 mm | 80 mm | 278 mm | 51 mm | 72 mm | 700c |
| 52 | 547 mm | 382 mm | 1.43:1 | 90 mm | 400 mm | 170 mm | 534 mm | 456 mm | 110 mm | 70.8° | 74.5° | 425 mm | 1016 mm | 604 mm | 80 mm | 278 mm | 51 mm | 71 mm | 700c |
| 54 | 560 mm | 388 mm | 1.44:1 | 100 mm | 420 mm | 172.5 mm | 543 mm | 473 mm | 125 mm |
Adds Fade Metallic / Dove Metallic. Drops Dune White / Smoke Liquid Metal.
The published chart moved versus 2025.
These are the verified 2026 builds. No 2025 sheet to compare.
2026 launch prices are in. No 2025 MSRP to compare.
Specialized S-Works Crux 2026 first ride reviewCyclist · 2026
Specialized 'Tarmacs' gravel with new CruxEscape Collective · 2026
The New Specialized Crux 5 Meets the Current Gravel ...Velo · 2026
Specialized Changed Everything About the New Crux, but It ...Bicycling · 2026
first ride review of the new Specialized Crux 5Cycling Weekly · 2026$3,999 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7120 105 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7100 105 | braze-on |
| Rear derailleur | Shimano | RD-R7100 105 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 50/34
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Wheels | Alloy | gravel wheelset |
| 71.0° |
| 74.5° |
| 425 mm |
| 1026 mm |
| 613 mm |
| 78 mm |
| 280 mm |
| 51 mm |
| 69 mm |
| 700c |
| 56 | 578 mm | 400 mm | 1.45:1 | 100 mm | 420 mm | 172.5 mm | 566 mm | 497 mm | 142 mm | 71.5° | 74.0° | 425 mm | 1039 mm | 626 mm | 78 mm | 280 mm | 51 mm | 66 mm | 700c |
| 58 | 598 mm | 412 mm | 1.45:1 | 110 mm | 440 mm | 175 mm | 583 mm | 515 mm | 163 mm | 71.5° | 74.0° | 425 mm | 1057 mm | 644 mm | 78 mm | 280 mm | 51 mm | 66 mm | 700c |
| 61 | 621 mm | 425 mm | 1.46:1 | 110 mm | 440 mm | 175 mm | 603 mm | 545 mm | 188 mm | 71.5° | 74.0° | 425 mm | 1078 mm | 665 mm | 78 mm | 280 mm | 51 mm | 66 mm | 700c |
700c |
| Tires | 700×33 | mm CX | — |
|---|
$4,499 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7170 105 Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7150 105 Di2 | braze-on |
| Rear derailleur | Shimano | RD-R7150 105 Di2 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 52/36
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Bottom bracket | Shimano | BSA threaded | — |
| Wheels | Alloy | gravel wheelset | 700c |
| Tires | 700×33 | mm CX | — |
$6,999 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | Force AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | Force AXS E1 | braze-on |
| Rear derailleur | SRAM | Force AXS E1 | 12-speed |
| Crankset | SRAM | Force E1 | 48/35
|
| Cassette | SRAM | XG-1270 E1 | 10-33, 12-speed |
| Chain | SRAM | Force E1 Flattop | 12-speed |
| Power meter | — | None | — |
| Brakes | SRAM | Force AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline X | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 | internal bearing |
| Wheels | Alloy | gravel wheelset | 700c |
| Tires | 700×33 | mm CX | — |
