Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 52). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 52 | 549 mm | 370 mm | 71.0° | 73.5° | 430 mm | 1025 mm | 72 mm |
| 54 | 567 mm | 376 mm | 71.5° | 73.5° | 430 mm | 1035 mm | 72 mm |
| 56 | 585 mm | 382 mm | 72.0° | 73.0° | 430 mm | 1045 mm | 70 mm |
| 58 | 603 mm | 388 mm | 72.0° | 73.0° | 430 mm | 1057 mm | 70 mm |
| 61 | 621 mm | 394 mm | 72.5° | 72.5° | 430 mm | 1069 mm | 68 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
