Loading geometry
Future Shock endurance road: extra stack, a suspended steer tube, and a ride that takes cobbles and chipseal without turning into gravel. Geometry is taller than Tarmac across the size run.
All-day road riders, Roubaix-fantasy cobble people, and anyone who found Tarmac too low.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 44 | 530 mm | 355 mm | 1.49:1 | 70 mm | 360 mm | 165 mm | 70.0° | 75.0° | 415 mm | 985 mm | 80 mm | 700c |
| 49 | 550 mm | 363 mm | 1.52:1 | 80 mm | 380 mm | 165 mm | 71.0° | 74.5° | 415 mm | 992 mm | 80 mm | 700c |
| 52 | 570 mm | 368 mm | 1.55:1 | 90 mm | 400 mm | 170 mm | 71.5° | 74.0° | 415 mm | 998 mm | 80 mm | 700c |
| 54 | 590 mm | 373 mm | 1.58:1 | 100 mm | 420 mm | 172.5 mm | 72.0° | 73.5° | 415 mm | 1005 mm | 78 mm | 700c |
| 56 | 610 mm |
These are the 2022 colors.
This is the earliest Roubaix year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
Specialized Roubaix Pro - Cycling News | Bike Reviewsroad.cc · 2022
The Specialized Roubaix Expert is sublime in many ways ...Cyclingnews · 2022
Tech-Redux From Issue #01: Specialized Roubaix S ...Velo · 2022
Specialized Roubaix Sport reviewCycling Weekly · 2022
Specialized Roubaix Elite reviewBikeRadar · 2018| 379 mm |
| 1.61:1 |
| 100 mm |
| 420 mm |
| 172.5 mm |
| 72.5° |
| 73.0° |
| 415 mm |
| 1015 mm |
| 78 mm |
| 700c |
| 58 | 632 mm | 385 mm | 1.64:1 | 110 mm | 440 mm | 175 mm | 72.5° | 73.0° | 418 mm | 1028 mm | 76 mm | 700c |
| 61 | 655 mm | 390 mm | 1.68:1 | 110 mm | 440 mm | 175 mm | 73.0° | 72.5° | 418 mm | 1040 mm | 76 mm | 700c |
