Loading geometry
Cube cyclocross race bike. Tight, muddy, UCI-oriented.
CX racers.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50 | 528 mm | 376 mm | 1.40:1 | 80 mm | 380 mm | 165 mm | 71.0° | 74.5° | 422 mm | 1006 mm | 68 mm | 700c |
| 53 | 546 mm | 382 mm | 1.43:1 | 90 mm | 400 mm | 170 mm | 71.5° | 74.0° | 422 mm | 1014 mm | 68 mm | 700c |
| 56 | 564 mm | 388 mm | 1.45:1 | 100 mm | 420 mm | 172.5 mm | 72.0° | 73.5° | 422 mm | 1024 mm | 66 mm | 700c |
| 58 | 582 mm | 394 mm | 1.48:1 | 110 mm | 440 mm | 175 mm | 72.0° | 73.5° | 422 mm | 1034 mm | 66 mm | 700c |
| 60 | 600 mm |
No colorway catalog for 2022 yet.
This is the earliest Cross Race C:62 year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
| 400 mm |
| 1.50:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 72.5° |
| 73.0° |
| 422 mm |
| 1046 mm |
| 64 mm |
| 700c |
| 62 | 620 mm | 406 mm | 1.53:1 | 110 mm | 440 mm | 175 mm | 72.5° | 73.0° | 422 mm | 1058 mm | 64 mm | 700c |
