Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 589 mm | 387 mm | 71.5° | 73.0° | 430 mm | 1047 mm | 80 mm |
| M | 569 mm | 379 mm | 71.0° | 73.5° | 430 mm | 1034 mm | 80 mm |
| S | 549 mm | 372 mm | 70.5° | 73.5° | 430 mm | 1024 mm | 80 mm |
| XS | 529 mm | 364 mm | 70.0° | 74.0° | 430 mm | 1014 mm | 80 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
