Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 589 mm | 395 mm | 72.0° | 73.0° | 425 mm | 1047 mm | 74 mm |
| M | 571 mm | 387 mm | 71.5° | 73.5° | 425 mm | 1035 mm | 74 mm |
| S | 553 mm | 379 mm | 71.0° | 73.5° | 425 mm | 1025 mm | 76 mm |
| XL | 607 mm | 403 mm | 72.0° | 72.8° | 425 mm | 1059 mm | 72 mm |
| XS | 535 mm | 371 mm | 70.5° | 74.0° | 425 mm | 1015 mm | 76 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
