Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 45). Category: road-race.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 45 | 501 mm | 374 mm | 71.0° | 75.0° | 406 mm | 967 mm | 72 mm |
| 48 | 517 mm | 380 mm | 71.8° | 74.5° | 406 mm | 975 mm | 72 mm |
| 51 | 533 mm | 386 mm | 72.5° | 74.0° | 406 mm | 983 mm | 70 mm |
| 53 | 549 mm | 392 mm | 73.0° | 73.5° | 406 mm | 991 mm | 70 mm |
| 56 | 567 mm | 398 mm | 73.0° | 73.0° | 406 mm | 1001 mm | 68 mm |
| 58 | 583 mm | 404 mm | 73.5° | 73.0° | 406 mm | 1013 mm | 68 mm |
| 61 | 599 mm | 410 mm | 73.5° | 72.5° | 406 mm | 1025 mm | 66 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
