Scott's lightweight race bike: slim, syncros-integrated on high kits, and a fit that is race-low. Foil is the aero sibling.
Climbers and racers who want Scott without Foil's deep aero.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Top tube | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XXS | 501 mm | 379 mm | 1.32:1 | 70 mm | 360 mm | 165 mm | 519 mm | 71.3° | 74.5° | 410 mm | 977 mm | 72 mm | 700c |
| XS | 512 mm | 386 mm | 1.33:1 | 80 mm | 380 mm | 165 mm | 528 mm | 71.8° | 74.5° | 410 mm | 983 mm | 72 mm | 700c |
| S | 526 mm | 392 mm | 1.34:1 | 90 mm | 400 mm | 170 mm | 542 mm | 72.3° | 74.0° | 410 mm | 989 mm | 72 mm | 700c |
| M | 543 mm | 395 mm | 1.37:1 | 100 mm | 420 mm | 172.5 mm | 555 mm | 72.8° | 73.6° | 410 mm | 991 mm |
No colorway catalog for 2027 yet.
The published chart moved versus 2026.
No verified spec sheet for 2027 or 2026.
No launch MSRP in the catalog yet.
We couldn't find any reviews for this model year.
| 72 mm |
| 700c |
| L | 564 mm | 403 mm | 1.40:1 | 110 mm | 440 mm | 175 mm | 572 mm | 73.4° | 73.3° | 410 mm | 999 mm | 70 mm | 700c |
| XL | 584 mm | 406 mm | 1.44:1 | 110 mm | 440 mm | 175 mm | 586 mm | 73.6° | 72.8° | 410 mm | 1006 mm | 70 mm | 700c |
| XXL | 604 mm | 411 mm | 1.47:1 | 110 mm | 440 mm | 175 mm | 602 mm | 73.8° | 72.5° | 410 mm | 1015 mm | 68 mm | 700c |
