Loading geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 2XS). Category: road-aero.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 2XS | 499 mm | 372 mm | 70.0° | 73.5° | 410 mm | 976 mm | 70 mm |
| L | 581 mm | 401 mm | 73.3° | 73.5° | 413 mm | 1004 mm | 70 mm |
| M | 561 mm | 393 mm | 73.3° | 73.5° | 410 mm | 989 mm | 70 mm |
| S | 540 mm | 390 mm | 72.8° | 73.5° | 410 mm | 983 mm | 70 mm |
| XL | 607 mm | 419 mm | 73.5° | 73.5° | 415 mm | 1030 mm | 70 mm |
| XS | 521 mm | 378 mm | 71.2° | 73.5° | 410 mm | 980 mm | 70 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
