Size chart for fitting. If this bike already feels right, find others with a similar riding position (size LA). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| LA | 579 mm | 387 mm | 71.5° | 73.5° | 428 mm | 1039 mm | 74 mm |
| MD | 561 mm | 379 mm | 71.0° | 73.5° | 428 mm | 1029 mm | 76 mm |
| SM | 543 mm | 371 mm | 70.5° | 74.0° | 428 mm | 1019 mm | 76 mm |
| XL | 597 mm | 395 mm | 72.0° | 73.0° | 428 mm | 1051 mm | 74 mm |
| XXL | 615 mm | 403 mm | 72.0° | 72.8° | 428 mm | 1063 mm | 72 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
