Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 48). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 48 | 499 mm | 375 mm | 71.0° | 74.5° | 420 mm | 987 mm | 79 mm |
| 51 | 524 mm | 384 mm | 71.5° | 74.0° | 420 mm | 996 mm | 79 mm |
| 54 | 549 mm | 393 mm | 72.0° | 73.5° | 420 mm | 1007 mm | 76 mm |
| 56 | 574 mm | 402 mm | 72.0° | 73.0° | 420 mm | 1025 mm | 76 mm |
| 58 | 599 mm | 411 mm | 72.0° | 73.0° | 420 mm | 1043 mm | 74 mm |
| 61 | 624 mm | 420 mm | 72.0° | 73.0° | 420 mm | 1060 mm | 74 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
