Fara F/AR 2022 geometry

No OEM studio shot for this year yet.

Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.

Size	Stack	Reach	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop
L	596 mm	400 mm	72.0°	73.0°	420 mm	1050 mm	72 mm
M	578 mm	392 mm	72.0°	73.5°	420 mm	1038 mm	72 mm
S	560 mm	384 mm	71.5°	73.5°	420 mm	1026 mm	74 mm
XL	614 mm	408 mm	72.5°	73.0°	420 mm	1062 mm	70 mm
XS	542 mm	376 mm	71.0°	74.0°	420 mm	1016 mm	74 mm

What it's like to ride

Drop-bar mixed-surface geometry: more trail and tire room than the road race bike, still not a mountain bike. Handling depends on whether this is the brand's race gravel or adventure gravel. Size M sits around 578 mm stack and 392 mm reach, 72° head angle, 420 mm chainstays.

Who it's for

Gravel riders. CX racers should check the brand's cyclocross chart; touring riders should look at mounts and stability, not just stack.

Manufacturer trims

F/AR Shimano 105 Di2

MSRP not listed

Component	Brand	Model	Size
Shifters	Shimano	ST-R7120 105 HRD	2×12
Front derailleur	Shimano	FD-R7100 105	braze-on
Rear derailleur	Shimano	RD-R7100 105	12-speed
Crankset	Shimano	FC-R7100 105	50/34 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R7100 105	11-34, 12-speed
Chain	Shimano	CN-M7100 SLX	12-speed
Power meter	—	None	—
Brakes	Shimano

Similar bikes

Size guidance

Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.

Fara F/AR 2022 geometry

No OEM studio shot for this year yet.

Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.

Size	Stack	Reach	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop
L	596 mm	400 mm	72.0°	73.0°	420 mm	1050 mm	72 mm
M	578 mm	392 mm	72.0°	73.5°	420 mm	1038 mm	72 mm
S	560 mm	384 mm	71.5°	73.5°	420 mm	1026 mm	74 mm
XL	614 mm	408 mm	72.5°	73.0°	420 mm	1062 mm	70 mm
XS	542 mm	376 mm	71.0°	74.0°	420 mm	1016 mm	74 mm

What it's like to ride

Who it's for

Gravel riders. CX racers should check the brand's cyclocross chart; touring riders should look at mounts and stability, not just stack.

Manufacturer trims

F/AR Shimano 105 Di2

MSRP not listed

Component	Brand	Model	Size
Shifters	Shimano	ST-R7120 105 HRD	2×12
Front derailleur	Shimano	FD-R7100 105	braze-on
Rear derailleur	Shimano	RD-R7100 105	12-speed
Crankset	Shimano	FC-R7100 105	50/34 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R7100 105	11-34, 12-speed
Chain	Shimano	CN-M7100 SLX	12-speed
Power meter	—	None	—
Brakes	Shimano

Size	Stem	Bar	Crank
L	110 mm	440 mm	175 mm
M	100 mm	420 mm	173 mm
S	90 mm	400 mm	170 mm
XL	110 mm	440 mm	175 mm
XS	80 mm	380 mm	165 mm

Fara F/AR 2022 geometry

What it's like to ride

Who it's for

Manufacturer trims

F/AR Shimano 105 Di2

Similar bikes

Size guidance

Fara F/AR 2022 geometry

What it's like to ride

Who it's for

Manufacturer trims

F/AR Shimano 105 Di2

Similar bikes

Size guidance

F/AR SRAM Rival AXS

F/AR Shimano Ultegra Di2

F/AR SRAM Force AXS

F/AR Shimano Dura-Ace Di2

F/AR SRAM RED AXS

Cockpit by size

Reviews

Component	Brand	Model	Size
Shifters	Shimano	ST-R7170 105 Di2 HRD	2×12
Front derailleur	Shimano	FD-R7150 105 Di2	braze-on
Rear derailleur	Shimano	RD-R7150 105 Di2	12-speed
Crankset	Shimano	FC-R7100 105	52/36 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R7100 105	11-34, 12-speed
Chain	Shimano	CN-M7100 SLX	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R7170 105	hydraulic disc
Rotors	Shimano	SM-RT70	160mm centerlock
Bottom bracket	Shimano	BSA threaded	—
Wheels	Alloy	gravel wheelset	700c
Tires	700x40mm	gravel	—

Component	Brand	Model	Size
Shifters	Shimano	ST-R8170 Ultegra Di2 HRD	2×12
Front derailleur	Shimano	FD-R8150 Ultegra Di2	braze-on
Rear derailleur	Shimano	RD-R8150 Ultegra Di2	12-speed
Crankset	Shimano	FC-R8100 Ultegra	52/36 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R8100 Ultegra	11-30, 12-speed
Chain	Shimano	CN-M8100 Ultegra	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R8170 Ultegra	hydraulic disc
Rotors	Shimano	SM-RT800	160mm / 140mm centerlock
Wheels	Alloy	gravel wheelset	700c
Tires	700x40mm	gravel	—

Component	Brand	Model	Size
Shifters	Shimano	ST-R9270 Dura-Ace Di2 HRD	2×12
Front derailleur	Shimano	FD-R9250 Dura-Ace Di2	braze-on
Rear derailleur	Shimano	RD-R9250 Dura-Ace Di2	12-speed
Crankset	Shimano	FC-R9200 Dura-Ace HollowTech II	52/36 XS165mm S170mm M172.5mm L175mm XL175mm
Cassette	Shimano	CS-R9200 Dura-Ace	11-30, 12-speed
Chain	Shimano	CN-M9100 Dura-Ace	12-speed
Power meter	—	None	—
Brakes	Shimano	BR-R9270 Dura-Ace	hydraulic disc
Rotors	Shimano	RT-MT900	160mm front / 140mm rear
Wheels	Carbon	40–45 mm gravel wheelset	700c
Tires	700x40mm	gravel	—
