Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 51). Category: Road Race.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 51 | 525 mm | 372 mm | 73.0° | 74.0° | 408 mm | 971 mm | 72 mm |
| 54 | 543 mm | 380 mm | 73.5° | 73.5° | 408 mm | 975 mm | 72 mm |
| 56 | 559 mm | 386 mm | 74.0° | 73.5° | 408 mm | 979 mm | 70 mm |
| 58 | 577 mm | 392 mm | 74.0° | 73.0° | 410 mm | 989 mm | 70 mm |
| Size | Stem | Bar | Crank |
|---|---|---|---|
| 51 | 90 mm | 400 mm | 170 mm |
| 54 | 100 mm | 420 mm | 173 mm |
| 56 | 100 mm | 420 mm | 173 mm |
| 58 | 110 mm | 440 mm | 175 mm |
A race-road geometry: lower stack, longer reach, steeper head angle, and short stays. It wants a committed position and rewards riders who already know their stack/reach. Size 56 sits around 568 mm stack and 390 mm reach, 74° head angle, 408 mm chainstays.
Racers and fit club riders. If you need a taller cockpit, look at the brand's endurance model on the same size chart.
We couldn't find any reviews for this model year.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7120 105 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7100 105 | braze-on |
| Rear derailleur | Shimano | RD-R7100 105 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 50/34
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Wheels | Alloy | road wheelset | 700c |
| Tires | 700x25mm | road | — |
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7170 105 Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7150 105 Di2 | braze-on |
| Rear derailleur | Shimano | RD-R7150 105 Di2 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 52/36
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Bottom bracket | Shimano | BSA threaded | — |
| Wheels | Alloy |
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R8170 Ultegra Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R8150 Ultegra Di2 | braze-on |
| Rear derailleur | Shimano | RD-R8150 Ultegra Di2 | 12-speed |
| Crankset | Shimano | FC-R8100 Ultegra | 52/36
|
| Cassette | Shimano | CS-R8100 Ultegra | 11-30, 12-speed |
| Chain | Shimano | CN-M8100 Ultegra | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R8170 Ultegra | hydraulic disc |
| Rotors | Shimano | SM-RT800 | 160mm / 140mm centerlock |
| Wheels | 40–50 | mm carbon wheelset |
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7170 105 Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7150 105 Di2 | braze-on |
| Rear derailleur | Shimano | RD-R7150 105 Di2 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 52/36
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Bottom bracket | Shimano | BSA threaded | — |
| Wheels | 40–50 |
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R9270 Dura-Ace Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R9250 Dura-Ace Di2 | braze-on |
| Rear derailleur | Shimano | RD-R9250 Dura-Ace Di2 | 12-speed |
| Crankset | Shimano | FC-R9200 Dura-Ace HollowTech II | 52/36
|
| Cassette | Shimano | CS-R9200 Dura-Ace | 11-30, 12-speed |
| Chain | Shimano | CN-M9100 Dura-Ace | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R9270 Dura-Ace | hydraulic disc |
| Rotors | Shimano | RT-MT900 | 160mm front / 140mm rear |
| Wheels | Carbon | race wheelset |
MSRP not listed
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7170 105 Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7150 105 Di2 | braze-on |
| Rear derailleur | Shimano | RD-R7150 105 Di2 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 52/36
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Bottom bracket | Shimano | BSA threaded | — |
| Wheels | Carbon |
| road wheelset |
700c |
| Tires | 700x25mm | road | — |
|---|
| Tires | 700x25mm | road | — |
|---|
| mm carbon wheelset |
700c |
| Tires | 700x25mm | road | — |
|---|
| Tires | 700x25mm | road | — |
|---|
| race wheelset |
700c |
| Tires | 700x25mm | road | — |
|---|
