Ribble aero road. Deep tubes, race position, the SL R's wind-cheating sibling.
Aero racers shopping Ribble.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 504 mm | 381 mm | 1.32:1 | 80 mm | 380 mm | 165 mm | 71.8° | 74.5° | 408 mm | 974 mm | 70 mm | 700c |
| S | 522 mm | 387 mm | 1.35:1 | 90 mm | 400 mm | 170 mm | 72.8° | 74.0° | 408 mm | 980 mm | 70 mm | 700c |
| M | 540 mm | 393 mm | 1.37:1 | 100 mm | 420 mm | 172.5 mm | 73.2° | 73.5° | 408 mm | 988 mm | 68 mm | 700c |
| L | 558 mm | 399 mm | 1.40:1 | 110 mm | 440 mm | 175 mm | 73.2° | 73.0° | 408 mm | 998 mm | 68 mm | 700c |
| XL | 576 mm | 405 mm |
No colorway catalog for 2020 yet.
This is the earliest Ultra year in the catalog. No prior year to compare.
No verified spec sheet for 2020 yet.
No launch MSRP in the catalog yet.
| 1.42:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 73.5° |
| 73.0° |
| 408 mm |
| 1010 mm |
| 66 mm |
| 700c |
