Loading geometry

Similar bikes
Scott's lightweight race bike: slim, syncros-integrated on high kits, and a fit that is race-low. Foil is the aero sibling.
Climbers and racers who want Scott without Foil's deep aero.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XXS | 505 mm | 370 mm | 1.36:1 | 70 mm | 360 mm | 165 mm | 70.5° | 74.5° | 410 mm | 978 mm | 72 mm | 700c |
| XS | 517 mm | 377 mm | 1.37:1 | 80 mm | 380 mm | 165 mm | 71.5° | 74.0° | 410 mm | 984 mm | 72 mm | 700c |
| S | 534 mm | 383 mm | 1.39:1 | 90 mm | 400 mm | 170 mm | 72.0° | 73.8° | 410 mm | 990 mm | 72 mm | 700c |
| M | 552 mm | 388 mm | 1.42:1 | 100 mm | 420 mm | 172.5 mm | 72.5° | 73.5° | 410 mm | 996 mm | 72 mm | 700c |
| L | 573 mm | 395 mm |
This year's studio shot is year-true studio.
This is the earliest Addict RC year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
SCOTT Addict RC Ultimate Disc ReviewGRAN FONDO Cycling Magazine · 2018
Scott Addict RC Pro Review | Editor's Choice 2019 | Cycling ...YouTube · 2019
Scott Addict RC Pro Review: 'A Stunning Blend Of ...YouTube · 2019
Scott Addict RC Ultimate review - Cyclist MagazineCyclist · 2020| 1.45:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 73.0° |
| 73.2° |
| 410 mm |
| 1008 mm |
| 70 mm |
| 700c |
| XL | 594 mm | 402 mm | 1.48:1 | 110 mm | 440 mm | 175 mm | 73.0° | 73.0° | 410 mm | 1020 mm | 70 mm | 700c |
| XXL | 615 mm | 408 mm | 1.51:1 | 110 mm | 440 mm | 175 mm | 73.3° | 72.8° | 410 mm | 1030 mm | 68 mm | 700c |
