Loading geometry
Specialized's gravel all-rounder. Future Shock up front (on many kits), generous tire room, and a position between Crux-race and touring. Recent Diverge 4 years shift clearance and front-end feel.
Gravel riders who want one bike for events and weekends. Racers who want a lower, racier gravel bike should also look at Crux.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 560 mm | 370 mm | 1.51:1 | 80 mm | 380 mm | 165 mm | 70.0° | 74.0° | 425 mm | 1025 mm | 80 mm | 700c |
| 52 | 578 mm | 377 mm | 1.53:1 | 90 mm | 400 mm | 170 mm | 70.5° | 73.7° | 425 mm | 1035 mm | 80 mm | 700c |
| 54 | 595 mm | 383 mm | 1.55:1 | 100 mm | 420 mm | 172.5 mm | 71.0° | 73.5° | 425 mm | 1045 mm | 78 mm | 700c |
| 56 | 612 mm | 390 mm | 1.57:1 | 100 mm | 420 mm | 172.5 mm | 71.5° | 73.2° | 425 mm | 1055 mm | 78 mm | 700c |
| 58 | 632 mm |
Adds Emerald / Silver Dust. Drops Carbon Metallic Spruce.
Same published geometry as 2025.
These are the verified 2026 builds. No 2025 sheet to compare.
2026 launch prices are in. No 2025 MSRP to compare.
Specialized Diverge 2026 on Test – Caught Between ...GRAN FONDO Cycling Magazine · 2025
The Specialized Diverge is our top choice for a gravel bike ...Cycling Weekly · 2026
Specialized Diverge 4 Expert review: Big, bouncy, and ...Cyclingnews · 2026
Specialized Diverge Comp review - Gravel BikesBikeRadar · 2018
$3,499 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7120 105 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7100 105 | braze-on |
| Rear derailleur | Shimano | RD-R7100 105 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 50/34
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Wheels | Alloy | gravel wheelset |
| 397 mm |
| 1.59:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 71.5° |
| 73.0° |
| 428 mm |
| 1068 mm |
| 76 mm |
| 700c |
| 61 | 655 mm | 404 mm | 1.62:1 | 110 mm | 440 mm | 175 mm | 72.0° | 72.8° | 428 mm | 1082 mm | 76 mm | 700c |
700c |
| Tires | 700×40 | mm gravel | — |
|---|
$4,199 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R7170 105 Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R7150 105 Di2 | braze-on |
| Rear derailleur | Shimano | RD-R7150 105 Di2 | 12-speed |
| Crankset | Shimano | FC-R7100 105 | 52/36
|
| Cassette | Shimano | CS-R7100 105 | 11-34, 12-speed |
| Chain | Shimano | CN-M7100 SLX | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R7170 105 | hydraulic disc |
| Rotors | Shimano | SM-RT70 | 160mm centerlock |
| Bottom bracket | Shimano | BSA threaded | — |
| Wheels | Alloy | gravel wheelset | 700c |
| Tires | 700×40 | mm gravel | — |
$6,499 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | Force AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | Force AXS E1 | braze-on |
| Rear derailleur | SRAM | Force AXS E1 | 12-speed |
| Crankset | SRAM | Force E1 | 48/35
|
| Cassette | SRAM | XG-1270 E1 | 10-33, 12-speed |
| Chain | SRAM | Force E1 Flattop | 12-speed |
| Power meter | — | None | — |
| Brakes | SRAM | Force AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline X | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 | internal bearing |
| Wheels | Alloy | gravel wheelset | 700c |
| Tires | 700×40 | mm gravel | — |
$7,999 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | RED AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | RED AXS E1 | braze-on |
| Rear derailleur | SRAM | RED AXS E1 | 36T max |
| Crankset | SRAM | RED AXS E1 with power meter | 48/35
|
| Cassette | SRAM | XG-1290 E1 | 10-33, 12-speed |
| Chain | SRAM | RED E1 Flattop | 12-speed |
| Power meter | SRAM | RED AXS E1 | spindle |
| Brakes | SRAM | RED AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline X | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 | internal bearing |
| Wheels | Carbon | 40–45 mm gravel wheelset | 700c |
| Tires | 700×40 | mm gravel | — |
