Pre-SLR Madone years: the aero Trek before Émonda disappeared. Older generations are heavier and more Kammtail than Gen 8; fit still sits in Trek's race family.
Riders shopping used or earlier aero Madones. For 2022-on, use Madone SLR pages.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 512 mm | 365 mm | 1.40:1 | 70 mm | 360 mm | 165 mm | 71.0° | 74.4° | 410 mm | 974 mm | 72 mm | 700c |
| 50 | 526 mm | 371 mm | 1.42:1 | 80 mm | 380 mm | 165 mm | 71.8° | 74.1° | 410 mm | 976 mm | 72 mm | 700c |
| 52 | 540 mm | 376 mm | 1.44:1 | 90 mm | 400 mm | 170 mm | 72.5° | 73.9° | 410 mm | 979 mm | 72 mm | 700c |
| 54 | 554 mm | 381 mm | 1.45:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 73.7° | 410 mm | 983 mm | 70 mm | 700c |
| 56 | 568 mm | 388 mm |
This year's studio shot is Trek Madone SL 6 2019 | Bikes.Fan.
This is the earliest Madone year in the catalog. No prior year to compare.
No verified spec sheet for 2019 yet.
No launch MSRP in the catalog yet.
Trek Madone SLR 9 Disc 2019 ReviewGRAN FONDO Cycling Magazine · 2018
2019 Trek Madone Gets Disc Brakes | Trek Road BikesBicycling · 2018
2019 Trek Madone SLR first-ride review: Upping the anteVelo · 2018
Help me decide: Trek Madone SLR 6 2019 vs. Cervelo S5 ...road.cc · 2018
Trek Madone SLR 9 Disc - Cycling News | Bike Reviewsroad.cc · 2019| 1.46:1 |
| 100 mm |
| 420 mm |
| 172.5 mm |
| 73.3° |
| 73.3° |
| 410 mm |
| 989 mm |
| 70 mm |
| 700c |
| 58 | 586 mm | 394 mm | 1.49:1 | 110 mm | 440 mm | 175 mm | 73.5° | 73.0° | 412 mm | 1001 mm | 68 mm | 700c |
| 60 | 604 mm | 399 mm | 1.51:1 | 110 mm | 440 mm | 175 mm | 73.8° | 72.8° | 412 mm | 1011 mm | 68 mm | 700c |
| 62 | 622 mm | 405 mm | 1.54:1 | 110 mm | 440 mm | 175 mm | 73.8° | 72.5° | 414 mm | 1022 mm | 68 mm | 700c |
