Loading geometry
Cervelo's lightweight race bike. It does not try to be an S5. Climbing, precise, and still a low WorldTour stack/reach chart.
Climbers and racers who want Cervelo without S5's deep aero cockpit. Soloist is the value race sibling.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | 496 mm | 369 mm | 1.34:1 | 80 mm | 380 mm | 165 mm | 71.0° | 74.5° | 410 mm | 977 mm | 77 mm | 700c |
| 51 | 520 mm | 377 mm | 1.38:1 | 90 mm | 400 mm | 170 mm | 72.0° | 74.0° | 410 mm | 978 mm | 77 mm | 700c |
| 54 | 545 mm | 383 mm | 1.42:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 73.5° | 410 mm | 978 mm | 74 mm | 700c |
| 56 | 568 mm | 391 mm | 1.45:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 73.0° | 410 mm | 993 mm | 74 mm | 700c |
| 58 | 591 mm | 400 mm |
This year's studio shot is 2022 Cervelo R5 Dura Ace Di2 Disc Value & Price Guide.
This is the earliest R5 year in the catalog. No prior year to compare.
No verified spec sheet for 2022 yet.
No launch MSRP in the catalog yet.
2022 Cervelo R5 Bike ReviewYouTube · 2022
Cervelo R5 Vs 2018 R5 - What Have They Changed?YouTube · 2018
Cervelo R5 eTap reviewBikeRadar · 2018
Official 2018 Cervelo R5 Frame and Fork Weight!YouTube · 2018
Cervelo R5 Road Bike | Lighter Than Ever | First Ride & ...| 1.48:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 73.0° |
| 73.0° |
| 410 mm |
| 1010 mm |
| 72 mm |
| 700c |
| 61 | 611 mm | 408 mm | 1.50:1 | 110 mm | 440 mm | 175 mm | 73.0° | 73.0° | 410 mm | 1025 mm | 72 mm | 700c |
