Loading geometry
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 544 mm | 372 mm | 1.46:1 | 90 mm | 400 mm | 170 mm | 70.5° | 74.0° | 430 mm | 1022 mm | 76 mm | 700c |
| M | 562 mm | 382 mm | 1.47:1 | 100 mm | 420 mm | 172.5 mm | 71.0° | 73.5° | 430 mm | 1034 mm | 76 mm | 700c |
| L | 580 mm | 392 mm | 1.48:1 | 110 mm | 440 mm | 175 mm | 71.5° | 73.5° | 430 mm | 1046 mm | 74 mm | 700c |
| XL | 598 mm | 402 mm | 1.49:1 | 110 mm | 440 mm | 175 mm | 72.0° | 73.0° | 430 mm | 1060 mm | 74 mm | 700c |
No colorway catalog for 2025 yet.
Same published geometry as 2024.
No verified spec sheet for 2025 or 2024.
No launch MSRP in the catalog yet.
