Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 48). Category: road-aero.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 48 | 501 mm | 380 mm | 71.8° | 74.5° | 405 mm | 971 mm | 70 mm |
| 51 | 519 mm | 386 mm | 72.8° | 74.0° | 405 mm | 977 mm | 70 mm |
| 54 | 537 mm | 392 mm | 73.2° | 73.5° | 405 mm | 985 mm | 68 mm |
| 56 | 555 mm | 398 mm | 73.2° | 73.0° | 405 mm | 995 mm | 68 mm |
| 58 | 573 mm | 404 mm | 73.5° | 73.0° | 405 mm | 1007 mm | 66 mm |
| 61 | 591 mm | 410 mm | 73.5° | 72.5° | 405 mm | 1019 mm | 66 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
