The mid-tier Cervelo race bike: less exotic than R5/S5, still a race position. A lot of riders' first Cervelo that actually fits like a race bike.
Racers who want Cervelo geometry without halo pricing. Compare stack/reach to R5.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48 | 502 mm | 368 mm | 1.36:1 | 80 mm | 380 mm | 165 mm | 71.0° | 73.0° | 410 mm | 975 mm | 75 mm | 700c |
| 51 | 522 mm | 376 mm | 1.39:1 | 90 mm | 400 mm | 170 mm | 72.0° | 73.0° | 410 mm | 978 mm | 75 mm | 700c |
| 54 | 543 mm | 384 mm | 1.41:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 73.0° | 410 mm | 981 mm | 72 mm | 700c |
| 56 | 566 mm | 392 mm | 1.44:1 | 100 mm | 420 mm | 172.5 mm | 73.0° | 73.0° | 410 mm | 995 mm | 72 mm | 700c |
| 58 | 588 mm |
This year's studio shot is Soloist PROFILE.
Same published geometry as 2025.
These are the verified 2026 builds. No 2025 sheet to compare.
2026 launch prices are in. No 2025 MSRP to compare.
$6,800 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | Rival AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | Rival AXS E1 | braze-on |
| Rear derailleur | SRAM | Rival AXS E1 | 12-speed |
| Crankset | SRAM | Rival E1 | 48/35
|
| Cassette | SRAM | XG-1250 E1 | 10-36, 12-speed |
| Chain | SRAM | Rival E1 Flattop | 12-speed |
| Power meter | — | None | — |
| Brakes | SRAM | Rival AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 |
| 401 mm |
| 1.47:1 |
| 110 mm |
| 440 mm |
| 175 mm |
| 73.0° |
| 73.0° |
| 410 mm |
| 1012 mm |
| 70 mm |
| 700c |
| 61 | 608 mm | 409 mm | 1.49:1 | 110 mm | 440 mm | 175 mm | 73.0° | 73.0° | 410 mm | 1026 mm | 70 mm | 700c |
internal bearing |
| Stem | Cervelo | ST36 alloy / HB13 alloy |
|
|---|
| Handlebar | Cervelo | ST36 alloy / HB13 alloy |
|
|---|
| Seatpost | Cervelo | SP24 carbon | — |
|---|
| Saddle | Selle Italia | Model 6 Superflow | — |
|---|
| Wheels | Reserve | 40/44 | 700c |
|---|
| Tires | Vittoria | Rubino Pro TLR, 700x28mm | — |
|---|
$8,500 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | Force AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | Force AXS E1 | braze-on |
| Rear derailleur | SRAM | Force AXS E1 | 12-speed |
| Crankset | SRAM | Force E1 | 48/35
|
| Cassette | SRAM | XG-1270 E1 | 10-33, 12-speed |
| Chain | SRAM | Force E1 Flattop | 12-speed |
| Power meter | — | None | — |
| Brakes | SRAM | Force AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline X | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 | internal bearing |
| Stem | Cervelo | ST36 alloy / HB13 alloy |
|
| Handlebar | Cervelo | ST36 alloy / HB13 alloy |
|
| Seatpost | Cervelo | SP24 carbon | — |
| Saddle | Selle Italia | Model 6 Superflow | — |
| Wheels | Reserve | 40/44 | 700c |
| Tires | Vittoria | Rubino Pro TLR, 700x28mm | — |
$8,250 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | Shimano | ST-R8170 Ultegra Di2 HRD | 2×12 |
| Front derailleur | Shimano | FD-R8150 Ultegra Di2 | braze-on |
| Rear derailleur | Shimano | RD-R8150 Ultegra Di2 | 12-speed |
| Crankset | Shimano | FC-R8100 Ultegra | 52/36
|
| Cassette | Shimano | CS-R8100 Ultegra | 11-30, 12-speed |
| Chain | Shimano | CN-M8100 Ultegra | 12-speed |
| Power meter | — | None | — |
| Brakes | Shimano | BR-R8170 Ultegra | hydraulic disc |
| Rotors | Shimano | SM-RT800 | 160mm / 140mm centerlock |
| Stem | Cervelo | ST36 alloy / HB13 alloy |
|
| Handlebar | Cervelo | ST36 alloy / HB13 alloy |
|
| Seatpost | Cervelo | SP24 carbon | — |
| Saddle | Selle Italia | Model 6 Superflow | — |
| Wheels | Reserve | 40/44 | 700c |
| Tires | Vittoria | Rubino Pro TLR, 700x28mm | — |
$11,000 · 2026 launch MSRP
| Component | Brand | Model | Size |
|---|---|---|---|
| Shifters | SRAM | RED AXS E1 HRD | 2×12 |
| Front derailleur | SRAM | RED AXS E1 | braze-on |
| Rear derailleur | SRAM | RED AXS E1 | 36T max |
| Crankset | SRAM | RED AXS E1 with power meter | 48/35
|
| Cassette | SRAM | XG-1290 E1 | 10-33, 12-speed |
| Chain | SRAM | RED E1 Flattop | 12-speed |
| Power meter | SRAM | RED AXS E1 | spindle |
| Brakes | SRAM | RED AXS E1 HRD | hydraulic disc |
| Rotors | SRAM | Paceline X | 160mm centerlock |
| Bottom bracket | SRAM | DUB T47 | internal bearing |
| Stem | Cervelo | ST31 carbon / HB13 carbon |
|
| Handlebar | Cervelo | ST31 carbon / HB13 carbon |
|
| Seatpost | Cervelo | SP20 carbon | — |
| Saddle | Selle Italia | Novus Boost Evo SuperFlow Carbon | — |
| Wheels | Reserve | 52/63 | 700c |
| Tires | Vittoria | Corsa Pro TLR, 700x28mm | — |
