Loading geometry
We couldn't find any reviews for this model year.
| Size | Stack | Reach | Stack/reach | Stem | Bar | Crank | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop | Wheel size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 51 | 520 mm | 377 mm | 1.38:1 | 90 mm | 400 mm | 170 mm | 72.5° | 74.0° | 405 mm | 972 mm | 70 mm | 700c |
| 54 | 540 mm | 385 mm | 1.40:1 | 100 mm | 420 mm | 173 mm | 73.0° | 73.5° | 405 mm | 978 mm | 70 mm | 700c |
| 56 | 558 mm | 391 mm | 1.42:1 | 100 mm | 420 mm | 173 mm | 73.2° | 73.5° | 405 mm | 984 mm | 68 mm | 700c |
| 58 | 578 mm | 397 mm | 1.45:1 | 110 mm | 440 mm | 175 mm | 73.2° | 73.0° | 407 mm | 994 mm | 68 mm | 700c |
