Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: road-race.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 564 mm | 394 mm | 73.0° | 73.0° | 408 mm | 1000 mm | 70 mm |
| M | 546 mm | 388 mm | 73.0° | 73.5° | 408 mm | 990 mm | 70 mm |
| S | 528 mm | 382 mm | 72.5° | 74.0° | 408 mm | 982 mm | 72 mm |
| XL | 582 mm | 400 mm | 73.5° | 73.0° | 408 mm | 1012 mm | 68 mm |
| XS | 510 mm | 376 mm | 71.5° | 74.5° | 408 mm | 976 mm | 72 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
