Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 50). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 50 | 545 mm | 372 mm | 70.5° | 74.0° | 428 mm | 1021 mm | 76 mm |
| 53 | 563 mm | 380 mm | 71.0° | 73.5° | 428 mm | 1031 mm | 76 mm |
| 55 | 581 mm | 388 mm | 71.5° | 73.5° | 428 mm | 1041 mm | 74 mm |
| 57 | 599 mm | 396 mm | 72.0° | 73.0° | 428 mm | 1053 mm | 74 mm |
| 59 | 617 mm | 404 mm | 72.0° | 73.0° | 428 mm | 1065 mm | 72 mm |
| 62 | 635 mm | 412 mm | 72.5° | 72.5° | 428 mm | 1077 mm | 72 mm |
Closest matches to this riding position — free, no login.
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
