Time Alpe d'Huez 2023 Geometry, Reviews, and Specs

Fit and steering

Aggressive fitSlow steeringFast steeringRelaxed fit

Weight—

Climbing7.2

Aero8.3

Comfort2.8

Size	Stack	Reach	Stack/reach	Stem	Bar	Crank	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop	Wheel size
XXS	507 mm	378 mm	1.34:1	70 mm	360 mm	165 mm	71.5°	74.5°	408 mm	974 mm	72 mm	700c
XS	525 mm	384 mm	1.37:1	80 mm	380 mm	165 mm	72.5°	74.0°	408 mm	980 mm	72 mm	700c
S	543 mm	390 mm	1.39:1	90 mm	400 mm	170 mm	73.0°	73.5°	408 mm	988 mm	70 mm	700c
M	561 mm	396 mm	1.42:1	100 mm	420 mm	172.5 mm	73.0°	73.0°	408 mm	998 mm	70 mm	700c
L	579 mm	402 mm

No colorway catalog for 2023 yet.

Same published geometry as 2022.

Published geometry matches the 2022 Time Alpe d'Huez. Same sizes, same stack and reach.

No verified spec sheet for 2023 or 2022.

Time's use of Vectran fibres, the new seatpost and Aktiv fork are examples of how the Alpe d'Huez is optimised to be as strong and stiff as possible, and if ...

No launch MSRP in the catalog yet.

The Time Alpe d'Huez 01 is super light, super stiff, and super expensive · Time Alpe d'Huez 01 first ride review · Time Alpe d'Huez first look.
